Application&Features

Type Analog

Weight 36g±1g

Size 40.8*20.1*38mm

Control System (+)Pulse Width Control 1500usec Neutral

Operating Voltage 6.0~7.4Volts

Operating Temperature Range (-)10 to +50 degree C

Operating Speed (6.0V) 0.12sec/60° at no load

Operating Speed (7.4V) 0.10sec/60° at no load

Stall Torque (6.0V) 3.0kg.cm

Stall Torque (7.4V) 3.5kg.cm

Operating Angle 45deg.one side pulse traveling 500 usec

Direction Anticlockwise/Pulse Traveling 1000~2000usec

Current Drain (6.0V) 20mA/idle and 160mA no load operating

Current Drain (7.4V) 20mA/idle and 200mA no load operating

Stall Current 0.8A/0.9A

Dead Band Width 4usec

Motor Type Iron Motor

Bearing Type Dual Ball Bearing*2

Horn gear spline 25T

Gear Type Plastic

Connector Wire Length 300mm±5mm

Wire info Brown/Black = Negative

Red = Positive

Orange/White = Signal
